Technical Data
|
General |
|
|
IP protection class |
IP 20 |
|
Cable diameter: |
5─11 mm |
|
Temperature range: |
-20°C bis +90°C |
|
Tightening torque (cable clamp screws): |
max. 30 Ncm |
|
Tightening torque (cover screws): |
max. 20 Ncm |
|
Material: |
|
|
Hood: |
ABS UL 94-V0 |
|
Colour: |
Black |
Dimensions
| Abmessungen / Dimensions | ||||
| Artikel / Part |
Polzahl / Pole Size |
A | B | d |
| 57 090 M | 09 (mm) | 31,7 | 38,0 | 10,0 |
| 57 150 M | 15 (mm) | 40,0 | 40,0 | 11,0 |
| 57 250 M | 25 (mm) | 53,0 | 40,0 | 11,0 |
| 57 255 M | 25 (mm) | 53,5 | 40,0 | 11,0 |
